| 型號 Model | YW-323 |
| 輸入電源 Voltage | AC 220V |
| 輸入功率 Input Power | 1.5KW |
| 頻率 Frequency | 35KHZ |
| 圓盤直徑 Desk Diameter | 1100MM |
| 工作面積 Work Plate Size | 450*550MM |
| 機器尺寸 Machine Size | 147*115*152CM |
特性 / Features:
1.本機為全自動化設計，當程序完成設置，本機會依照設定的軌跡開始作業。
This machine is designed with fully automation, once program is done with setting up, this machine will run automatically based on the requested positions in the program.
2.本機設有兩個點焊頭，一個工位一次點一雙鞋面，配合轉盤式設計，一個工位在操作點超聲波時，另一個工位進行收料與擺料，大大提高工作效率與產量。
This machine is designed with turntable station and two welding heads. While one station is ultrasonic positioning upper (one pair at a time), operator can collect finished materials and place new materials on the other station. With this design, this machine is not only able to increase efficiency and productivity, but also reduce waiting time.
3.本機裝置優質紅外線激光定位燈，不僅精準對位鞋面，同時可依照需求調節紅色焦點大小。
This machine is equipped with a high quality infrared laser positioning light, which can accurately position uppers. The size of red focusing can also be adjusted based on requests.
